Specifications
| Detect gas | Ozone O3 |
| Sensors principle | electrochemistry |
| Sampling method | diffusion |
| Range | 0~10PPm |
| resolution | 0.01PPm |
| detection Accuracy | ≤ +/- 3% (Actual concentration, higher Accuracy required according to Sensors performance) |
| Operation mode | Infrared remote control for remote and close operation, easy to set up |
| Repeatability | ≤±1% |
| Zero drift | ≤ +/- 1% (F. S/year) |
| Response time | ≤25s(T90) |
| recovery time | ≤20s |
| Explosion-proof sign | Exd II CT6 |
| Protection level | IP66 |
| Output signal | Users can be determined according to the actual site environment needs, up to 2000 meters (single core 1mm2 Shielding cable) |
| main material | Shell: ADC12 aluminum alloy, strong, wear-resistant and corrosion-resistant (316 stainless steel shell is optional) |
| Installation method | Wall-mounted, pipeline type |
| Operating temperature | -30~60℃ |
| Environmental humidity | ≤ 95% RH, no condensation (Humidity > 90% RH, condensation can be equipped with Filter) |
| Relative Humidity | 10%~95%RH |
| Power Supply | 24VDC (Normal Operating Voltage range 12~ 30VDC) |
| power consumption | 1.5W |
| Operating Pressure | ≤200Kpa |
| Dimension | 180*140*92mm |
| Weight | About 1.6Kg |
| execution standard | GB15322.1-2003，GB3836.1-2010，GB3836.2-2010，GB3836.4-2010 |
Packing list
Host x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/9206/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
