Specifications
| Protective layer thickness measurement (nominal) range | The first Measurement Range: 6mm~ 90mm; the second Measurement Range: 7mm~ 220mm; |
| Measurement range of steel bar diameter | Ф6~Ф50mm |
| Steel protective layer thickness Measured value MPE | Protective layer thickness first range (nominal) range 6~ 59mm ：≤ +/- 1mm; 60~6 9mm ：≤ +/- 2mm; 70~90mm ：≤ +/- 4mm; protective layer thickness second range (nominal) range 7~ 7 9mm ：≤ +/- 1mm; 80~119 mm ：≤ +/- 2mm; 120~200mm ：≤ +/- 4mm |
| Measured value MPE range | +/- 1st gear |
| Display | 160×128mm |
| Normal operation Environmental requirements | Operating temperature: -10 ℃~ + 40 ℃; Relative Humidity: < 90% RH (no corrosion gas in the air; no strong electromagnetic interference;) |
| Power Supply | Rechargeable battery with a Power Supply time of up to 50 hours |
| Host size | 220×165×90mm |
| Probe Volume | 105×55×30mm |
Packing list
Host x1, probe X1, cable X1, charger X1, measurement car X1, software CD X1, instrument case X1, manual x1, warranty card x1, certificate x1
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/9570/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
