Specifications
| Film thickness range of application (mm) | 6 ～ ╹ 50 |
| Test range (mm) | The first range: 1~ 90; the second range: 5~ 185 |
| Film thickness MPE (mm) | ±1（1～70）；±2（60～100）；±4（80～180） |
| With error correction | Error correction range: -3.0~ + 3.0 (ie ± 0.5, ± 1.0, ± 1.5, ± 2.0, ± 2.5, ± 3.0) |
| Diameter Measurement Range (mm) | 6 ～ ╹ 50 |
| Maximum error of diameter measurement (specification) | ±1 |
| scan mode | Film thickness mode, grid view, section mode, waveform mode, JGJ detection |
| Scanning range | borderless |
| Data transfer mode | USB |
| Power Supply | Built-in high-Capacity lithium battery |
| Set shutdown time | 5m、10m、15m、30m、60m、90m |
| Operating Temperature | -10℃～+42℃ |
| Weight | 0.6kg |
Packing list
Host x1, charger X1, USB data cable X1, software CD-ROM X1, instrument case X1, crayon X1, manual x1, warranty card x1, certificate x1
After-sales instructions
Warranty days: 1095 days
【After-sales service】
1. The product enjoys a three-year warranty from the date of purchase, and the warranty is responsible for the original factory;
2. Consumables, man-made damage or damage caused by improper use are not within the scope of free maintenance;
3. If the quality problem identified by the original factory does not affect the secondary sales, you can apply for a refund within 7 days and replace the goods within 15 days. Returns and exchanges due to selection errors will not be accepted, please confirm the specifications and models before purchasing.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/9571/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
