Defelsko PosiTector 6000 FRS1 import Thickness Gauge paints/film/film thickness measurement

SE
90 degree magnetic Induction probe, used for low clearance area thickness measurement, waterproof probe can be underwater measurement; can flip display touch LCD screen, support screenshot; with sound and visual alarm; USB interface can transmit data and charge.
$1024.00/set
PromotionLoading...
Coupon
Certificate
Contact
Details SPEC Con VIDEO CAT OI
Similar products

Defelsko PosiTector 6000 FRS1 Coating Thickness GaugeSPEC

Defelsko PosiTector 6000 FRS1 Coating Thickness GaugeDetails

Defelsko PosiTector 6000 FRS1 Coating Thickness GaugePacking list

SKU
NB000981
Measurement principle
Magnetic Induction
Measurement range
0~1500μm
margin of error
±1%
Resolution
0.1μm
probe
FRS1 probe (90 ° universal type)
statistical function
Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation
icon function
without
Power Supply
3 * AAA alkaline battery
Standards
ISO 2178/2360/2808、PrEN ISO 19840、ASTM B499/D1186/D1400/D7091/E376/G12、BS3900-C5、SSPC-PA2等
Calibrated Certificate
Yes.
Language
Chinese, English
Display screen
2.8-Inch color touchscreen
Interface
USB
supporting software
PosiSoft Software Suite
Machine Weight
137G (without battery)
Machine size
127*66*25.4mm
Data storage
1000 Measured values
Test environment
Ferrous metal substrate nonmagnetic coating environment
Defelsko calibrated standard
STDS1、STDA1
screen image saving
One hundred.
Protection level
IP65
Measurement speed
60 + readings per minute
PosiTector 6000 FRS1
Coating Thickness Gauge
90 degree magnetic Induction probe, used for low clearance area thickness measurement, waterproof probe can be underwater measurement; can flip display touch LCD screen, support screenshot; with sound and visual alarm; USB interface can transmit data and charge.
Defelsko PosiTector 6000 FRS1 import Thickness Gauge paints/film/film thickness measurement Picture

Coating Thickness Gauge selector

Introduction

Defelsko PosiTector 6000 FRS1The imported Thickness Gauge is a standard type Thickness Gauge for measuring the non-magnetic coating of ferrous metal substrates, with a measurement range of 0~1500μm. The Defelsko PosiTector 6000 FRS1 Coating Thickness Gauge is a 90-degree probe type, the probe is anti-abrasion, and the gauge is backlit for operation.

New features have been added to the new version of the Defelsko PosiTector console in the United States

Defelsko Devs high brand introduction

Defelsko PosiTector 6000 FRS1 imported Thickness Gauge probe accuracy

The Defelsko PosiTector 6000 Coating Thickness Gauge can be equipped with a variety of transducers

Comparison of the features of the Defelsko PosiTector 6000 Advanced and Standard models in the United States

Advantages of the protective function of the Defelsko PosiTector 6000 FRS1 imported Thickness Gauge from the United States

Defelsko PosiTector 6000 FRS1 Imported Thickness Gauge Other features:

Defelsko PosiTector 6000 FRS1 Imported Thickness Gauge Typical application areas

Why Choose North and South Tide to Buy the Defelsko PosiTector 6000 FRS1 Imported Thickness Gauge from the United States?

Recommended reading

★《How do you choose the Defelsko PosiTector 6000 Coating Thickness Gauge?》

★Defelsko PosiTector 6000 Series Coating Thickness Gauge Details (Text Version)

FAQ
QI want to measure paints Film thickness on ferrous metal, which thickness gauge should I choose?
A The Defelsko PosiTector 6000 FRS1 Coating thickness gauge is recommended. This one uses the principle of magnetic Induction and is specially used for the measurement of nonmagnetic coatings on ferrous metal substrates, such as paints, powder coatings, etc. The measurement range 0-1500 μm is fully sufficient, with an accuracy of +/- 1%. It also has statistical functions to suit your needs.
QIn which industries is this thickness gauge used more?
A PosiTector 6000 FRS1 is widely used in industrial painting, automobile manufacturing, ship maintenance, steel structure corrosion protection and other industries. Because it conforms to ISO, ASTM and other international standards, it can accurately measure paints, epoxy resin and other coating thickness to ensure that mass painting meets the specification requirements.
QI want to measure paints Film thickness on ferrous metal surface, which thickness gauge should I choose?
A The Defelsko PosiTector 6000 FRS1 Coating thickness gauge is recommended. This instrument uses the principle of magnetic Induction and is specially used for the measurement of nonmagnetic coatings on ferrous metal substrates, such as paints, coatings, etc. Its measurement range 0-1500 μm fully covers the requirements of conventional coating thickness, with an accuracy of +/- 1%. It is easy to operate and has statistical functions. It is suitable for industrial field use.
QI want to measure the thickness of paints Film. Which thickness gauge should I use?
A The Defelsko PosiTector 6000 FRS1 is recommended for measuring nonmagnetic coatings on ferrous metal substrates, such as paints. The measurement range 0-1500 μm is fully sufficient, the accuracy +/- 1% is accurate, and the Probe is wear-resistant and durable.
QWhy choose the FRS1 Probe?
A FRS1 is a 90-degree general-purpose Probe, which is convenient for measuring planes and surfaces, and is particularly resistant to abrasion. With a color Touchscreen and 1000 pieces of storage, you can directly see the statistical results after on-site testing, and it is also very convenient to export the data with USB.
QDo the Defelsko 6000 series thickness gauges come standard with software?
A This does not have a physical software CD, but PosiSoft software can be downloaded for free on the manufacturer's official website for downloading and viewing data reports.
QWhy can't the Defelsko Coating thickness gauge be charged?
A Hello, there are two solutions: 1. It is equipped with 3 ordinary AA batteries, please open it and replace it; 2. It can also be connected to a computer for direct use, but it cannot be charged (powered by a USB cable).
QDoes the Defelsko Coating thickness gauge meet the ASTME376 standard?
A The PosiTector 6000 FRS1 Coating thickness gauge can refer to
QCan this one test the coating thickness of the inner wall of the pipe?
A Sure
