TQC AB3055 stainless steel coating bar 14μm WFT Total length 440mm
The Dutch TQC stainless steel coating bar AB3055 is an imported wire-wound Mayer Rods, the film thickness is 14μm, and the stainless steel coating bar AB3055 can have a preparatory application width of 320mm.
Model：
TQC sheen AB3055 Mayer RodsSPEC
TQC sheen AB3055 Mayer RodsDetails
TQC sheen AB3055 Mayer RodsPacking list
- SKU
- NB009824
- Production process
- Wire-wound
- WFT
- 14μm
- Total length
- 440mm
- Application width
- 320mm
- grip width
- 60+60mm
- material
- stainless steel
AB3055
Mayer Rods
Introduction
The coating width of the Dutch TQC wire-wound stainless steel scraper is 320mm, and the thickness of the wet film that can be prepared is 4~200μm.
Wire bar applicators, also known as threaded wire bars, are ideal for preparing films on paper or plastic. In addition, it is also suitable for film making on soft substrates. TQC stainless steel scraper is made of stainless steel, which has good acid and alkali resistance. Stainless steel squeegee rods can be used in conjunction with automatic coating machines.
Product parameters
| Model | Wet film thickness | Coating width | Overall length | Straightness | Material | craft |
| AB3050 | 4μm | 320 mm | 440mm | < 50 μm | stainless steel | Winding |
| AB3051 | 6μm | |||||
| AB3052 | 8μm | |||||
| AB3053 | 10μm | |||||
| AB3054 | 12μm | |||||
| AB3055 | 14μm | |||||
| AB3056 | 15μm | |||||
| AB3057 | 20μm | |||||
| AB3058 | 24μm | |||||
| AB3059 | 30μm | |||||
| AB3060 | 34μm | |||||
| AB3061 | 42µm | |||||
| AB3062 | 40μm | |||||
| AB3063 | 50μm | |||||
| AB3064 | 56μm | |||||
| AB3065 | 60μm | |||||
| AB3066 | 76μm | |||||
| AB3067 | 100μm | |||||
| AB3068 | 120μm | |||||
| AB3069 | 200μm |
Optional
|
|
|
FAQ
QSolid content 18%, expected to make Dry-Film 3 microns, this stick number is OK?
A
Sure
