Specifications
| Maximum measurement | 10KN |
| Effective detection range | 1%-100% |
| Load Graduation | 1N |
| Load measurement Accuracy | Within ± 1% of the indication |
| Drawing speed | 1mm-50mm/min |
| Specimen range | 300×500mm |
| Film thickness | 70mm |
| Stretch stroke | 150mm |
| Drive mode | Servo motor drive |
| Power | Single-phase AC 220V/50Hz, motor power 200 W |
| Dimensions | 700*700*830mm |
| Weight | 115KG |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/18966/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
