SANFA DHG-9030 Electric thermostatic drying oven 30L

SE
Temperature range RT + 10~ 250 ℃, Temperature stability +/- 1 ℃, Temperature resolution 0.1 ℃, Temperature uniformity +/- 2 ℃, Volume 30L, Interior size 300 * 300 * 350mm
$261.55/set
PromotionLoading...
Coupon
Model:

sanfa DHG-9030 Electric thermostatic drying ovenSPEC

sanfa DHG-9030 Electric thermostatic drying ovenDetails

sanfa DHG-9030 Electric thermostatic drying ovenPacking list

SKU
NB025974
Temperature range
RT+10~250℃
Temperature stability
±1℃
Temperature resolution
0.1℃
Temperature uniformity
±2℃
volume
30L
Interior size
300*300*350mm
Chamber material
Spray high temperature resistant silver paint
Shelf (std.)
2pcs
Outer box material
Good steel plate welded, surface electrostatic spray
Timer
1~9999min
Power
220V 50Hz
Input Power
500W
Dimensions
420*420*660mm
Communication interface
RS-485 (optional)
DHG-9030
Electric thermostatic drying oven
Temperature range RT + 10~ 250 ℃, Temperature stability +/- 1 ℃, Temperature resolution 0.1 ℃, Temperature uniformity +/- 2 ℃, Volume 30L, Interior size 300 * 300 * 350mm
SANFA DHG-9030 Electric thermostatic drying oven 30L Picture

Application

It is suitable for drying, baking, melting wax, and sterilization in industrial and mining enterprises, laboratories, and scientific research units.

Features

※The inside and outside of the cabinet are welded with high-quality steel plates, the surface is electrostatically sprayed, the working room is made of mirror stainless steel or sprayed with high temperature resistant silver paint, the door is equipped with observation windows or double door structure, the shape is novel, beautiful and energy-saving.

※Microcomputer intelligent digital display temperature controller, accurate and reliable temperature control, simultaneously displays the set temperature and the temperature in the box, with alarm functions for overheating, leakage, sensor failure, and timing function. (Optional intelligent LCD temperature controller).

※A low-noise fan and a suitable air duct are used to form a hot air circulation system, and the dry hot air is directly dried and sterilized by the heated object.

※In addition to the above functions, the upgraded liquid crystal display temperature controller also has programmable temperature control, can be equipped with RS-485 interface, can be connected to a recorder and a computer, and can record the change of temperature parameters (optional).

Model

modelvolumepowerTemperature control range
DHG-9030(A)30500RT+10-250
DHG-9070(A)701000RT+10-250
DHG-9140(A)1401500RT+10-250
DHG-9240(A)2252000RT+10-250
DHG-9101-0(A)43500RT+10-300
DHG-9101-1(A)701000RT+10-300
DHG-9101-2(A)1401500RT+10-300
DHG-9101-3(A)2252000RT+10-300
Other parameters
temperature resolution0.1°C
temperature fluctuation±1℃
temperature uniformity±2°C (test point is 100°C)
Carrier2pcs (standard configuration)
timing range1-9999min
voltage220V 50Hz
Remarks: A is stainless steel liner
Unit: L, W, °C
