SANFA DHG-9101-1A Electrothermal thermostatic drying oven 70L/stainless steel

SE
70L stainless steel liner, Temperature range RT + 10-300 ℃, Temperature Fluctuation +/- 1 ℃, Temperature resolution 0.1 ℃, Temperature Uniformity +/- 2 ℃, Timing 1-9999min, with overheating alarm and RS-485 interface (optional).
$452.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con CAT OI
Similar products

SANFA DHG-9101-1A Electric thermostatic drying ovenSPEC

SANFA DHG-9101-1A Electric thermostatic drying ovenDetails

SANFA DHG-9101-1A Electric thermostatic drying ovenPacking list

SKU
NB025985
Temperature range
RT+10~300℃
Temperature Fluctuation
±1℃
Temperature Resolution
0.1℃
Temperature Uniformity
±2℃
Volume
70L
Interior size
350*450*450mm
Chamber material
stainless steel
Shelf (std.)
2pcs
Enclosure Material
Good steel plate welded, surface electrostatic spray
Timer
1~9999min
Power
220V 50Hz
Input Power
1000W
Dimensions
480*610*820mm
Communication interface
RS-485 (optional)
DHG-9101-1A
Electric thermostatic drying oven
70L stainless steel liner, Temperature range RT + 10-300 ℃, Temperature Fluctuation +/- 1 ℃, Temperature resolution 0.1 ℃, Temperature Uniformity +/- 2 ℃, Timing 1-9999min, with overheating alarm and RS-485 interface (optional).
SANFA DHG-9101-1A Electrothermal thermostatic drying oven 70L/stainless steel Picture

Application

It is suitable for drying, baking, melting wax, and sterilization in industrial and mining enterprises, laboratories, and scientific research units.

Features

※The inside and outside of the cabinet are welded with high-quality steel plates, the surface is electrostatically sprayed, the working room is made of mirror stainless steel or sprayed with high temperature resistant silver paint, the door is equipped with observation windows or double door structure, the shape is novel, beautiful and energy-saving.

※Microcomputer intelligent digital display temperature controller, accurate and reliable temperature control, simultaneously displays the set temperature and the temperature in the box, with alarm functions for overheating, leakage, sensor failure, and timing function. (Optional intelligent LCD temperature controller).

※A low-noise fan and a suitable air duct are used to form a hot air circulation system, and the dry hot air is directly dried and sterilized by the heated object.

※In addition to the above functions, the upgraded liquid crystal display temperature controller also has programmable temperature control, can be equipped with RS-485 interface, can be connected to a Recorder and a computer, and can record the change of temperature parameters (optional).

Model

modelvolumepower
DHG-9101-0(A)43L500W
DHG-9101-1(A)70L1000W
DHG-9101-2(A)140L1500W
DHG-9101-3(A)225L2000W
same parameters
Voltage220V 50Hz
Temperature control rangeRT+10-300℃
temperature resolution0.1°C
temperature fluctuation±1℃
temperature uniformity±2°C (test point is 100°C)
Carrier2pcs
Timer Range1-9999min
Remarks: A is stainless steel liner
Library
FAQ
QOur laboratory wants to buy a drying oven, which is mainly used for conventional baking and sterilizing. Is there any recommendation?
A This DHG-9101-1A is very suitable. Its volume is 70L, Temperature range is 300 ℃, daily drying and sterilizing are enough. And this one uses a low-noise fan and circulating air duct, Temperature Uniformity can reach +/- 2 ℃, and the effect on Sample Handling is very stable. The cost performance is also quite high, I recommend you consider this one.
QWe often need to run the equipment for a long time to process samples. Can this drying oven handle this scenario?
A Yes. This model has a timing function of 1-9999 minutes. You can set the time in advance and automatically stop at the point, so that it will be worry-free to run for a long time. In addition, it also has over-temperature, leakage and Sensor fault alarm functions. In case of problems, it will be reminded in time to ensure safe use and rest assured.
QWe want to use this equipment for High Accuracy experiments and need to record temperature data. What suggestions do you have?
A If you want to record data, I recommend choosing the upgraded model. It can be equipped with an RS-485 interface, which can connect a computer and a recorder to record temperature changes. Linear dispersion. In addition, the LCD temperature controller also has a programmable function, which can meet more complex experimental needs. Although the basic model can also control temperature, the upgraded model is more suitable for you for data traceability.
QCan this one be equipped with a ventilation device and an over-temperature alarm?
A The drying oven can naturally change air, and the over-temperature alarm meter also comes with it
QCan your oven meet this GB/T30435-2013?
A meet
QThe machine can control the temperature of 205 ° C, and about 60L of test pieces should be placed.
A Can meet, DHG-9101-1A electrothermal thermostatic blast drying oven Temperature range 10~ 300 ℃, volume 70L.
QHelp me find an electric thermostatic drying oven that meets GB/T16777 standard
A This DHG-9101-1A electric thermostatic drying oven is ok!
