Specifications
| Temperature range | -20~150℃ |
| Temperature fluctuation | ≤±0.5℃ |
| Temperature uniformity | ≤±1.5℃ |
| Humidity control range | 20~98%R.H |
| Humidity fluctuation | ±2%R.H |
| Humidity uniformity | ±3.0%R.H、-2.0%R.H |
| Power | 220V/±10%V 50Hz |
| Interior size | 500*400*500mm |
| Dimensions | 1000*1100*1450mm |
| Interior volume | 100L |
| Cooling rate | 1 ℃/min (no-load nonlinear) |
| heating rate | 3 ℃/min nonlinear no-load |
| heating rate | RT + → 150 ℃ │ 40min (no-load nonlinear) |
| Cooling rate | RT + → -40 ℃ │ 60min (no-load nonlinear) |
| Inner box material | USU #304 Mirror Stainless Steel (1MM thick) |
| Outer box material | Painted panel |
| Refrigeration system | Using original French Taikang compressor, environmentally friendly refrigerants R404A and R23A, fin type condenser with heat dissipation evaporator, evaporator: fin type multi-stage automatic load capacity adjustment |
| controller | Using original TEM series control system such as TEMI880 color Chinese and English touch condenser or TEMI300 English button controller |
| safety device | No fuse switch, compressor high pressure, overheating, overcurrent protection, over temperature protection, fan overload protection, fuse, dry burn protector, water shortage alarm protection |
| Communication function | 232 or 485 online, with software CD and 1 set of connecting data cable, optional USB interface |
| Display | LCD touch panel |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/40850/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
