It is used for drying, baking, wax melting, disinfection and sterilization of non-flammable and explosive items and non-volatile items for industrial and mining enterprises, colleges and universities, biopharmaceuticals, food processing, scientific research, medical units and various laboratories. use.
1. Horizontal, back heating type, horizontal forced convection ensures uniform temperature in the studio;
2. The temperature control system uses high-performance CPU processing chips and high-sensitivity, high-precision platinum resistance sensors to make temperature control more precise and easier to operate;
3. It has sensor fault alarm, over-temperature alarm, self-diagnosis dynamic control, temperature display correction, parameter memory and timing functions up to 999 minutes.
model | DHG-9023A | DHG-9053A | DHG-9123A | DHG-9203A | |
working conditions | Ambient temperature 5ï½30℃ | ||||
Relative humidity â¤80% | |||||
Altitude ⤠2000m | |||||
Power supply AC220V±10% 50Hz±1Hz | |||||
Way of working | LCD display, push-button type, microprocessor temperature control with fuzzy PID control technology | ||||
High precision platinum resistance sensor | |||||
Forced circulation convection duct | |||||
Optional 0~9999 minutes or hour timing | |||||
temperature | Control range | Rt+10ï½200℃ | |||
Accuracy | 0.1℃ | ||||
Volatility | ±1℃ | ||||
Call the police | SV+5℃(factory value) | ||||
Power consumption | 650W | 850W | 1500W | 2050W | |
Material | studio | 304 stainless steel plate | |||
shell | 08F cold rolled steel plate | ||||
Number of shelves (standard/optional) | 2/3 | 2/3 | 2/3 | 2/4 | |
weight | net weight | 36KG | 50KG | 72.5KG | 91KG |
Dimensions (mm) | studio | 300Ã300Ã275 | 420Ã350Ã350 | 550Ã350Ã550 | 600Ã550Ã600 |
shape | 580Ã470Ã445 | 710Ã520Ã520 | 830Ã530Ã720 | 880Ã740Ã790 |
