Specifications
| Spreader mode | Bar Spreader |
| Bar Spreader Thickness Range | 1-571.5 μm (Spreader thickness according to bar model) |
| Bar Spreader accuracy | ±0.001mm |
| Spreader rate | 5-200Mm/s (< 5mm/s can be customized) |
| Bottom plate material | Glass plate |
| Control Panel | LCD touch screen |
| Substrate fixing method | Mechanical fixture |
| Shaft transmission mode | timing belt |
| Feeding principle | Air source pressure flows out |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2-150mm/s |
| spit volume | Adjustable (by adjusting the air pressure and the running speed of the discharge port) |
| Volume of sealing drum | 1 kg (with automatic mixing function) |
| Feeding system air source | 0.6Mpa, can be connected to the trachea of φ 8 (self-equipped) |
| Power voltage of charging system | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding bucket configuration | Safety valve, pressure regulating valve, pressure gauge, discharge valve |
| Feeding drum volume | 1L |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, air knife drying, remote control, upper infrared heating, double extrusion Spreader |
| Power voltage | 220V,50Hz |
| Power supply voltage | Single phase 220V 50Hz 100VA |
| weight | 180kg |
| Dimension | 880 * 1000 * 500Mm (subject to actual design parameters) |
Packing list
Film Applicator x1, Automatic Inking System x1, Import bar x1
After-sales instructions
None
