Specifications
| barrel | monocular |
| Flat field eyepiece | WF10X / f18 ・ WF16X / f11 |
| Objective for eliminating color difference | 4X/0.10, 10X/0.25, 40X/0.65 (spring), 100X/1.25 (oil, spring) |
| Total magnification | 40X~1600X |
| Monocular observation head | 45 ° tilt, 360 ° swirl/spin |
| converter | Four holes (external ball positioning) |
| Coarse fine-tuning focus range | 15mm micro-motion grid value: 2um coarse micro-motion coaxial focusing, limit |
| stage | Double-layer mechanical type, size 125X115mm Moving range 70X30mm Vernier grid value 0.1mm |
| Mechanical barrel length | 160mm |
| condenser | 1.25NA Abbe condenser, variable light bar with color filter (up and down) |
| lighting | Brightness adjustable, tungsten halogen bulb 6V20W |
| condenser | Abbe Condenser Variable Bar and Color Filter |
| eyepiece | Wide-angle eyepiece WF10X, Huygens eyepiece H16X |
| Objective for eliminating color difference | 4X,10X,40X(S), 100X(S) |
| lighting | Halogen lamp 6V/20W |
| Power | Electric light source |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7261/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
