AOLONGXINGDI HBS-62.5 digital display small load Brinell Hardness Tester

AOLONGXINGDI HBS-62.5 digital small load Brinell Hardness Tester is a new type of brinell Hardness Tester using precision mechanical technology and photoelectric technology. The maximum height of the HBS-62.5 specimen is 160mm, and the distance from the indenter to the machine wall is 135mm.
Model：
Certificate
Contact
Details SPEC CAT

AoLongXingDi HBS-62.5 Digital low load Brinell Hardness TesterSPEC

AoLongXingDi HBS-62.5 Digital low load Brinell Hardness TesterDetails

AoLongXingDi HBS-62.5 Digital low load Brinell Hardness TesterPacking list

SKU
NB015418
test force
61.25N(6.25kgf),98.07N(10kgf),153.2N(15.625kgf), 294N(30kgf),306.25N(31.25kgf),612.9N(62.5kgf)
execution standard
EN, ISO 6507, EN ISO 6506, ASTM E-384, ASTM E-10-08, ASTM E-384 GB/T231.2，JJG150
Maximum height of specimen
160mm
Head to wall distance
135mm
Dimension
250*550*650mm
Test force holding time
5~60s
Test force application method
automatic
Microscope magnification
40x，100x
Hardness Measurement range
8-650 HBW
Power Supply
AC220V/50HZ
Weight
45kg
HBS-62.5
Digital low load Brinell Hardness Tester
AOLONGXINGDI HBS-62.5 digital display small load Brinell Hardness Tester Picture

Introduction

HBS-62.5 Digital Display Small Load Brinell Hardness Tester is a new type of Brinell Hardness Tester using precision mechanical technology and photoelectric technology. The machine is controlled by an embedded microcomputer, which is suitable for cast iron, non-ferrous metals and their alloys, and various annealed and quenched and tempered steels.


Scope of application

It is especially suitable for the hardness testing of softer metals such as pure aluminum, lead and tin, and is a satisfactory Brinell hardness testing instrument for research and testing by scientific research institutions, enterprises and quality inspection departments

Features

●Adjust the intensity of the measurement light source

●Real-time display of test environment temperature

●The data is displayed on the large touch screen and comes with a database, which can be easily stored, queried and read

●Hardness test data is printed, which is easy to use

●High measurement accuracy
