KSJ WGG60-Y4 gloss meter Reading Range 0.0~199.9GU

KSJ WGG60-Y4 gloss meter Measuring Area is 36x18mm, is a portable digital gloss meter, WGG60-Y4 display is 31/2 digital display, WGG60-Y4 gloss meter is suitable for paints, paint, architectural coatings, marble, ceramics, water paint, metal, plastic and other surface gloss measurement.
Model：
Certificate
Contact
Details SPEC CAT OI
Similar products

KSJ Gloss meterSPEC

KSJ Gloss meterDetails

KSJ Gloss meterPacking list

SKU
NB002167
Measurement angle
60°
Measurement range
0~199.9GU
Measuring Areas
18*36mm
Error of indication
±1.2GU
Graduation
0.1GU
Standards
ISO2813、GB9754、ASTM D2457、ASTM D523、GB/T13891、GB7706、GB8807、JJG696-2002
Display
31/2 digit digital display
Dimensions
130*40*80mm
Weight
430g
Power
Built-in Ni-MH battery pack 4x1.2V
Measurement port size
20*50mm
Reading Range
0~199.9GU
Zero Error
0.2GU
Stability
0.4GU
Operating Time
Power-on continuous use time > 48h
Charging time
14~16h
Charger
AC 187~ 242 (50Hz)
Gloss meter
KSJ WGG60-Y4 gloss meter Reading Range 0.0~199.9GU Picture

product description

Palm size, easy to carry.

Built-in rechargeable battery pack. A full charge can last for more than 24 hours.

Application scope

★Measurement of surface gloss of paint, baking varnish, paint, ink, etc.

★Building decoration materials: surface gloss measurement of marble, granite, vitrified polished tiles, ceramic tiles, etc.

★Measurement of surface gloss of plastic, paper, bamboo and wood.

★Surface gloss measurement of various other non-metallic and metallic materials.

Structure diagram

Cosjia WGG60-Y4 gloss meter structure diagram

Cosjia WGG60-Y4 gloss meter working plate

Standards compliant

WGG60-Y4 gloss meter complies with the standards ISO2813, GB9754, ASTM D2457, ASTM D523, GB/T13891, GB7706, GB8807, JJG696-2002 "Mirror Gloss Meter and Gloss Plate" metrological verification regulations for first and second level working machines. Require. The gloss value of the WGG60-Y4 gloss meter can be traced to the Shanghai Institute of Metrology and Testing Technology (SIMT) glossiness international benchmark.

plan

Koshijia WGG60-Y4 gloss meter display picture

Ke Shijia after-sales service commitment letter

FAQ
QTest Marble Glossiness, Can You Use KSJ Y4?
A Sure.
QHow is this WGG60-Y4 gloss instrument adjusted?
A Hello, adjustment method: Turn on the power supply, remove the dust cover, and place the measuring port on the adjustment work board (black Glass). After half a minute, adjust the "adjustment" button to make the displayed value equal to the verification value of the black work board. Note that the measuring port of the Gloss meter needs to be buckled into the positioning frame of the work board, and the adjustment indication is valid.
QHow long can the WGG60-Y4 Gloss meter last on a single charge?
A Hello, the WGG60-Y4 gloss meter can be turned on and used for more than 24 hours after being fully charged.
