TAISITE SYG-A2-8 intelligent Electric Thermostatic Water Bath double row eight holes
SEDK series upgrade, double row eight holes, natural water convection heat transfer, Temperature range RT + 5~ 100 ℃, working tank material stainless steel plate, heater stainless steel heating tube, Rated power 2.0Kw, Temperature control mode PID
Model：
SYG-A2-8
Similar products
TaiSiTe SYG-A2-8 Electric thermostatic Water BathSPEC
TaiSiTe SYG-A2-8 Electric thermostatic Water BathDetails
TaiSiTe SYG-A2-8 Electric thermostatic Water BathPacking list
- SKU
- NB029134
- number of holes
- double row eight holes
- way
- Natural water convective heat transfer
- Temperature range
- RT+5~100℃
- Temperature Resolution
- 0.1℃
- Temperature Fluctuation
- ±0.5℃
- Temperature Uniformity
- ±1.0℃
- Interior
- stainless steel plate
- exterior
- Cold rolled steel plate, surface resistant painting
- heat insulation material
- polyurethane
- Heating device
- Stainless steel heating pipe
- Rated power
- 2.0Kw
- Temperature control mode
- PID
- Temperature setting method
- Tap the button to set
- Timer Range
- 0~999Min (with Timer and waiting function)
- Operational Features
- Fixed value operation, regular operation, automatic stop
- Program Mode
- optional
- Additional features
- Deviation correction, menu button lock, power outage compensation, power outage memory
- Sensors
- CU50
- Safety Devices
- Overrise alarm
- Tank Size
- 635*325*120mm
- Dimension
- 794*398*200mm
- packing size
- 863*477*235mm
- Shelf load bearing
- 5kg
- Shelf layer
- 1st floor
- Power supply Voltage
- AC220V/9.1A 50/60Hz rated current
- Net Weight
- 10KG
- Gross Weight
- 12KG
SYG-A2-8
Electric thermostatic Water Bath
DK series upgrade, double row eight holes, natural water convection heat transfer, Temperature range RT + 5~ 100 ℃, working tank material stainless steel plate, heater stainless steel heating tube, Rated power 2.0Kw, Temperature control mode PID
Application: precision constant temperature, auxiliary heating
Features
1. Stainless steel liner.
2. PID control, precise temperature control
3. Convenient operation, fixed value operation, timing operation, automatic stop.
4. Special function keys for temperature setting.
5. Auxiliary menu to realize overheating alarm, deviation correction and menu lock.
6. Patent No.: ZL03348684.0
Safety: overheating alarm, menu lock
Models
| model | power | Inner dimension | Internal volume | |
| Single digital temperature controller | Intelligent temperature controller | |||
| SYG-1-1 | SYG-A1-1 | 0.4Kw | 168*168*120mm | 3.4L |
| SYG-1-2 | SYG-A1-2 | 0.5Kw | 325*168*120mm | 6.6L |
| SYG-1-4 | SYG-A1-4 | 1.0Kw | 653*168*120mm | 13.2L |
| SYG-1-6 | SYG-A1-6 | 1.5Kw | 945*168*120mm | 19.1L |
| SYG-2-4 | SYG-A2-4 | 1.0Kw | 325*325*120mm | 12.7L |
| SYG-2-6 | SYG-A2-6 | 1.5Kw | 480*325*120mm | 18.7L |
| SYG-2-8 | SYG-A2-8 | 2.0Kw | 635*325*120mm | 24.8L |
| Operating temperature range | RT+5~100℃ | |||
| Heating time | ≤40 minutes | |||
| temperature resolution | 0.1°C | |||
| temperature fluctuation | ±0.5℃ | |||
| Temperature Distribution | ±1.0℃ | |||
| Interior | stainless steel plate | |||
| Exterior | Cold-rolled steel sheet with chemical-resistant coating on the surface | |||
| Insulation material | Polyurethane | |||
| heater | stainless steel heating tube | |||
| Way | natural water convective heat transfer | |||
| temperature control method | Using microcomputer PID to control heater output | |||
| temperature setting method | Touch three buttons for action, digital display setting | |||
| Temperature representation | Measured temperature display: 3-digit upper display; set temperature display: 3-digit lower display | |||
| timer | 0~999 minutes (with timing waiting function) | |||
| running function | Fixed value operation, timing operation, automatic stop | |||
| program mode | Single segment operation | |||
| Additional features | Deviation correction, menu key lock, power failure compensation, power failure memory | |||
| sensor | NTC | |||
| partition load | 5kg | |||
| Partition layers | 1 story | |||
| safety devices | Overheating alarm | |||
| configuration can be added | Partition board, RS485 interface, Recorder, external communication, need to replace LCD instrument | |||
