APPLENT AT5210 Resistance meter

APPLENT AT5210 Multi-channel Resistance meter Precision resistance: 0.5%, Voltage: 0.05%, Measurement range Resistance: 0.01mΩ~ 33.000Ω, Voltage: 0.00001V~ 60.000VDC, AT5210 Multi-channel Resistance meter uses vector star method, multiple parameters simultaneous measurement.
Model：
Certificate
Contact
Details SPEC CAT

Applent AT5210 Resistance meterSPEC

Applent AT5210 Resistance meterDetails

Applent AT5210 Resistance meterPacking list

SKU
NB032369
test parameters
10 AC resistors, 10 DC Voltages
Basic Precision
Resistance: 0.5% Voltage: 0.05%
Measurement range
Resistance: 0.01mΩ~ 33.000Ω Voltage: 0.00001V~ 60.000VDC
signal source
AC 1kHz, test current: < 150mA
range
Three-range automatic and manual
Test speed
Fast 10 ways/1 second, medium speed 10 ways/2 seconds, slow speed 10 ways/3 seconds
Show results
Direct reading, Delta ABS, delta%, theta, sorting result
MAX reading
Resistance: 3,0000 Voltage: 60,000
correction
Short circuit clearing in full scale
comparator
RHI/RNG/RLO output VHI/VNG/VLO output absolute value tolerance +/- TOL sorting, percentage tolerance TOL sorting, sequential comparison sorting
trigger
Internal trigger, manual trigger, external trigger and remote trigger
interface
RS-232C interface Handler interface (PLC interface)
power requirements
Voltage: 195VAC~ 245VAC Frequency: 50Hz Power: 15VA
Size and Weight
External Dimensions (mm): 264 (W) x107 (H) x350 (D) Weight: 4kg
Accessories
ATL505 Kelvin test cable, ATL108 RS232 interface cable
Optional Accessories
ATL506A test probe ATL506 test watch rod
Miscellaneous
Test line damage detection True color TFT-LCD display, keypad lock and data retention function Internal flash memory and USB flash drive Data Logging
AT5210
Resistance meter
APPLENT AT5210 Resistance meter Picture

Performance characteristics

  • The vector method is used to measure the star, and a variety of parameters are measured at the same time.

  • Comparator (sorting) function

  • Test lead damage detection.

  • Compatible with SCPI instruction set.

  • New and improved sampling circuitry

apply

  • Tests of various contact resistances

  • Alkaline batteries, lead-acid batteries, and lithium batteries deterioration measurement and life evaluation

  • UPS online detection

  • Battery factory inspection

  • Supercapacitor equivalent resistance (ESR) measurements
