Specifications
| combustion box | The box size is 300mm wide x 1200 x 450mm deep; |
| Combustion blowtorch | 1KW combustion nozzle (made according to GB/T5169.14-2007/IEC60695-11-2:2003 standard), the height of the blue flame center is 50~60mm, and the Total height of the flame is 170~190mm. |
| combustion gas | Using high-purity 95% technical-grade propane gas (or gas replacement) |
| Specimen length | 600±25mm； |
| Specimen holder | The distance between the lower edge of the upper bracket and the upper edge of the lower bracket of the two horizontal brackets is 550mm; |
| Holding time | 0.1-999.9S continuous setting, the flame can continuously combustion the sample within the set time; |
| Blowtorch installation location | The blue flame contact point is 475mm away from the lower edge of the horizontal upper bracket, and the angle between the blowtorch and the vertical axis of the sample is 45 degrees |
| Control mode | Manual or automatic options; |
| Gas flow range | 100-1000mL/min； |
| Air flow range | 1-10L/min； |
| pressure gauge | 0~ 0.75Kpa range adjustment |
| Ignition method | High Voltage automatic ignition |
Packing list
Host X1, exhaust pipe X1, throat buckle X1, flame height measurement ruler X1, receiving tray X1, absorbentcottonph X1, power cord X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36469/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
