3NH spectroscopic color difference treasure CR9 + (advanced enhanced version) four aperture, large area array Sensors grating spectroscopy
The repeability Delta E * ab is easily controlled within 0.03. Equipped with four measurement diameters, fast charging, full-band balanced LED light source, and APP measurement is more convenient.
Model：
CR9+
Similar products
3NH CR9+ Spectroscopic color difference treasureSPEC
3NH CR9+ Spectroscopic color difference treasureDetails
3NH CR9+ Spectroscopic color difference treasurePacking list
- SKU
- NB036938
- Lighting method
- D/8 (diffuse illumination, 8 ° direction reception) SCI/SCE measurement, in accordance with CIE No. 15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7
- Integrating sphere size
- Φ40mm
- lighting source
- Light spectrum LED light source, UV light source
- spectroscopy
- Plane grating spectroscopy
- Sensor
- Silicon photodiode array (dual row 32 groups)
- Measurement Wavelength range
- 400~700nm
- wavelength interval
- 10nm
- Half bandwidth
- 10nm
- Measurement range
- L: 0~120 reflectance: 0~200%
- Measurement caliber
- Four caliber: φ 12mm, φ 8mm, φ 4mm, 1x3mm
- Focus method
- Optical inspection focus + electronic focus
- Light-containing method
- Simultaneous testing of SCI/SCE
- Color space
- CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,βxy,DIN Lab9,DIN Lab99 Munsell(C/2)
- color difference formula
- ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99
- Other chroma metrics
- WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), Isochromatic Index Mt, colour fastness, color fastness, force, occlusion, Formula Guide
- Viewing Angle
- CIE 2°/10°
- observation light source
- D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30)
- display mode
- Light spectrum plots/data, sample chromatic values, color difference values/plots, pass/fail results, Color simulation, Color bias
- Display Accuracy
- 0.01
- Measurement time
- Approximately 1.5 seconds (approximately 3.2 seconds for simultaneous SCI/SCE testing)
- Sexual repeability
- Chromatic value: MAV/SCI, Delta E * ab within 0.03 (after preheating correction, the average value of 30 whiteboard measurements at intervals of 5s)
- stand-alone difference
- ΔE*ab<0.3(MAV/SCI)
- measurement mode
- Single measurement, average measurement (2~ 99 times)
- positioning method
- camera positioning, stabilizer positioning
- Dimensions
- 81*71*214mm
- Weight
- About 460g
- battery life
- Lithium battery, 6000 cycles in 8 hours
- Lifetime of lighting source
- More than 3 million measurements in 5 years
- Display
- TFT true color 3.5inch, capacitive touch screen
- Data Interface
- USB, Bluetooth ® 5.0
- data storage
- 1000 master standards, 30,000 samples (one data can include SCI/SCE at the same time), APP Mass storage
- operating language
- Simplified Chinese, English, Traditional Chinese
- Operating environment
- 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m
- Storage environment
- -20~50 ℃, 0~85% RH (no condensation)
- optional accessories
- USB micro printer, powder test box, Bluetooth micro printer, placement base
CR9+
Spectroscopic color difference treasure
The repeability Delta E * ab is easily controlled within 0.03. Equipped with four measurement diameters, fast charging, full-band balanced LED light source, and APP measurement is more convenient.
