Specifications
| temperature Measurement Range | -20~550℃ |
| temperature measurement resolution | 0.1℃ |
| Detector type | Vanadium oxidation uncooled infrared focal plane Detector |
| Corresponding band | 8~14um |
| Pixel size | 12um |
| NETD | <50mK |
| Field of view | 56°×42.2° |
| spatial resolution | 3.8mrad |
| Focusing method | Focus free |
| Accuracy | ±2℃/±2% |
| Detector resolution | 256x192 |
| Temperature measurement tool | Center point temperature measurement/cold point hot spot tracking |
| Image display mode | Thermal imagery dual light fusion PIP IMIX visible light |
| pseudo-color | 7 kinds |
| Temperature alarm | Full frame high temperature/low temperature alarm |
| Photo function | Support, with temperature data |
| quadratic analysis | Equipped with PC analysis software for secondary analysis of data |
| Display | 2.8"，240*320 |
| lighting | LED fill light |
| storage device | Standard 16GB SD card, support expansion |
| Temperature unit conversion | Celsius/Fahrenheit/Kelvin |
| Operating Time | 11H@25 ℃ indoor |
| Drop protection | 3m |
| Power battery | Built-in rechargeable lithium battery |
| Product net Weight | 522g |
| Dimensions | 222.3*74.7*84.3mm |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39784/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
